| 最大切割长度 | 2800 mm | Max Cutting Length: 2800 mm |
| 最大切割宽度 | 1350 mm | Max Cutting Width: 1350 mm |
| 切割厚度范围 | 10–60 mm | Cutting Thickness Range: 10–60 mm |
| 切割精度 | ±0.1 mm | Cutting Accuracy: ±0.1 mm |
| 切割方式 | 平行水平裁切 | Cutting Method: Parallel Horizontal Cutting |
| 主电机功率 | 5.5–7.5 kW | Main Motor Power: 5.5–7.5 kW |
| 输送方式 | 自动上料 定制 | Feeding Method: Automatic Feeding |
| 控制系统 | PLC/数控系统，可编程 | Control System: PLC/CNC, Programmable |
| 锯片直径 | 400–600 mm | Saw Blade Diameter: 400–600 mm |
| 锯片转速 | 2800–4500 rpm | Saw Blade Speed: 2800–4500 rpm |
| 切割行程 | 根据板材尺寸可调 | Cutting Stroke: Adjustable according to panel size |
| 材料适用 | PP蜂窝板及轻质复合板 | Applicable Material: PP Honeycomb Panels and Lightweight Composite Boards |
| 安全保护 | 防护罩、安全急停按钮 | Safety Features: Protective Cover, Emergency Stop Button |
| 外形尺寸 | 4200 × 1800 × 1500 mm | Machine Dimensions: 4200 × 1800 × 1500 mm |
| 重量 | 1800–2000 kg | Machine Weight: 1800–2000 kg |
| 生产能力 | 可连续加工，效率视板材厚度和尺寸而定 | Production Capacity: Continuous operation, efficiency depends on panel thickness and size |
